44
Error messages
Parameter Browser
Parameter Browser related error messages are listed in the following table.
Table 9. Parameter Browser-related error messages
Error message
Cause
Solution
Given value was invalid. Please input valid
value.
The value you are trying to give
does not fit between minimum and
maximum values of the parameter.
Check the minimum and maximum
values and give a proper value.
Drive status
The drive status-related error messages are listed in the following table.
Table 10. Drive status-related error messages
Error message
Cause
Solution
Communication error occurred while
uploading status word.
No communication between the
drive and DriveConfig.
Check the connection to the drive
and communication settings and try
again.
Communication error occurred while
downloading command word.
You have given Reverse command
before Start or there is no
communication between the drive
and DriveConfig.
Give Start command first and then
reverse. Check the connection to
the drive and communication
settings and try again.
Communication error occurred while
downloading reference parameter.
No communication between the
drive and DriveConfig.
Check the connection to the drive
and communication settings and try
again.
Error occurred while uploading command
word.
No communication between the
drive and DriveConfig.
Check the connection to the drive
and communication settings and try
again.
Communication error occurred while
uploading reference register.
No communication between the
drive and DriveConfig.
Check the connection to the drive
and communication settings and try
again.
Errors occurred while updating Status
panel.
No communication between the
drive and DriveConfig.
Check the connection to the drive
and communication settings and try
again.
