Vitek VT-1671 [7/48] Vt 1671 qxd 10 1 5 11 28 page 7
![Vitek VT-1671 [7/48] Vt 1671 qxd 10 1 5 11 28 page 7](/views2/1056299/page7/bg7.png)
7
FIRST USE SAFETY RECOMMENDATION
Please read through this booklet for safe and efficient
use of the appliance. We urge you to read the "impor-
tant Safeguards" section and also follow all detailed
instructions even if you are familiar with a similar appli-
ance.
Keep this guide handy for future reference.
IMPORTANT SAFEGUARDS
When using electrical appliances, in order to reduce the
risk of lire, electric shock, and/or injury to persons,
basic safety precautions should be followed, including
the following:
Read all instructions carefully, even if you are famil-
iar with the appliance.
Before using this appliance for the first time make
sure that local mains voltage corresponds to the
operational voltage of the appliance.
To avoid the risk of electric shock, NEVER
IMMERSE the appliance, power cord or the mains
plug in water or other liquids.
Use a damp cloth to clean the appliance.
Close supervision is required when the appliance is
used near children.
Never leave running appliance unattended.
Always unplug the appliance before using the appli-
ance for the first time, assembly, dismantling or
cleaning. Never pull on the cord, always hold the
plug.
Do not operate the appliance with a damaged cord
or plug, or when the appliance malfunctions, or is
dropped or damaged in any other manner. Return
the complete appliance to your nearest authorized
service center for examination, electrical repair or
mechanical repair or adjustment.
Use only the accessories provided by the manufac-
turer.
See that the power cord never hangs over the edge
of the table or touches hot surfaces.
Never place the appliance on or near a hot surface
(such as gas or electric Stove or heated oven).
Handle the power cord carefully. Never carry the
appliance by the cord.
This appliance is intended for household use only.
Do not attempt to repair the appliance yourself;
instead, take it to the authorized service center.
IDENTIFICATION OF PARTS
1. Pusher
2. Food tray
3. Mincer head
4. Mincer button
5. Base unit
6. Power switch (ON/OFF)
7. Reverse button (REV)
8. Low speed button
9. Key for ring nut
10. Fine-mincing screen plate
11. Coarse-mincing plate
12. Feeder screw
13. Crossed-knife blade
14. Medium-mincing screen plate
15. Ring nut
16. 17. Sausage attachment.
18. 19. Kebbe attachment
20. Pusher for vegetable cutter
21. Vegetable cutter unit
22. Shredder
23. Coarse grater
24. Fine grater
Y
our meat Mincer Features:
Primary and supplementary operating speed - pri-
mary operating speed for all types of meat mincing,
supplementary speed for processing of soft vegetables
such as tomatoes.
Reverse mode - to remove blocks while mincing.
Big metal food tray - provides convenient supply of
food in the course of processing.
Three screen plates with opening of various sizes -
for various degrees of meat mincing.
Special attachments - for making sausages and
kebbes.
Overload protection system - prevents overload to
protect and enhance motor life.
IF THE MINCER SUDDENLY STOPPED:
- switch it off by pressing ON/OFF button (5).
- unplug the appliance.
- let the motor cool down for 60 minutes.
- rerun the appliance.
HOW TO ASSEMBLE YOUR MEAT MINCER
Before first use, please remove all packaging materials
from the unit and wipe it with a damp cloth. Wash the
parts other than the base unit in warm soapy water and
allow drying.
MEAT MINCING
1. Insert the feeder screw (12) into the mincer head
(3), fix the crossed-knife blade (13), take the
required screen plate (10, 11, 14) and fix it above
the knife by aligning the screen plate groove with
the mincer head pin, tighten the nut lightly (15). Fig.
1.
Attention:
the appliance with the knife improperly aligned
(cutter side toward the feeding screw) won't mince
when assembling the mincer head, do not tighten
the nut (15) too strong, the nut (15) should be final-
ly tightened only after mounting of the assembled
mincer head on the base unit.
2. Mount the assembled mincer head and turn it anti-
clockwise to fix. Fig. 2.
3. Place the food tray (2). Fig. 3.
4. Connect the appliance to the mains.
5. Switch on the neat mincer by pressing ON/OFF but-
ton (5).
6. To process soft vegetables, such as tomatoes, use
the low speed of rotation by pressing the low speed
button(8).
7. Always use the pusher (1) only. Fig. 4.
ENGLISH
Vt-1671.qxd 10.01.05 11:28 Page 7
