129

specifies a existed RADIUS server to configure to be the RADIUS server of current domain.

For example:

!Configure current domain to use RADIUS configuration of “test”

QTECH(config-aaa-test.com)#radius host test

3. Use access-limit to enable command to configure the maximum number of access user

that can be contained in current domain.

For example:

!Configure the maximum number of access user that can be contained in

domain test.com to 100

QTECH(config-aaa-test.com)#access-limit enable 100

4. Use state command to configure the state of the domain to be active or block.

For example:

!Activate test.com

QTECH(config-aaa-test.com)#state active

5. Use default domain-name to enable command to configure a existed domain to be default

domain. If the domain doesn’t exist, the configuration fails. Use default domain-name

disable command to disable the default domain.

When the default domain name is disabled, switch will not deal with the invalid packet, if the

username goes without the domain name. After the default domain name is enabling, switch

will add @ and default domain name to a username wothout a domain name to authenticate.

To configure a default domain which must be existed, or the configuration fails.

For example:

!Configure default domain name to be test.com and enable the default

domain

QTECH(config-aaa)#default domain-name enable test.com

6. Use show domain command to display the configuration of the domain.

For example:

!Display the configuration of the domain

QTECH(config-aaa-test.com)#show domain

9.2.4 Configure local-user

When local-user authentication is configured, the local username and password should be

added.
