+7(495) 797-3311 www.qtech.ru
Москва, Новозаводская ул., 18, стр. 1
88
6.1.3 ACL support
ACL can be classified as following:
ACL is the command control list applied to switch. These command is used to tell switch which
data packet to receive and which to refuse. It consists of a series of judging syntax. After
activating an ACL, switch will examine each data packet entering switch according to the
judging condition given by ACL. The one which satisfies the ACL will be permit or dropped
according to ACL. QOS introduces the permit rule configuration.
In system, the ACL can be classified as following:
Standard ACL based on number ID
Standard ACL based on name ID
Extended ACL based on number ID
Extended ACL based on name ID
Layer 2 ACL based on number ID
Layer 2 ACL based on name ID
The restriction to every ACL and number of QOS action is as following table:
ACL number restriction
Standard ACL based on number ID
1-99
99
Extended ACL based on number ID
100-199
100
Layer 2 ACL based on number ID
200-299
100
Standard ACL based on name ID
--
1000
Extended ACL based on name ID
--
1000
Layer 2 ACL based on name ID
--
1000
Sub-rule number which can be configured by an ACL
0-127
128
The max sub-rule number which can be configured
--
3000
Time range
--
128
The absolute time range which can be configured by a time range
--
12
The periodic time range which can be configured by a time range
--
32
Sub-item of activating ACL
--
460
6.2 ACL configuration
6.2.1 Configuration list
ACL configuration includes:
Configure time range
Define ACL
