mode, interface
configuration can
enter other
interface mode
and VLAN
configuration
mode without
inputting ―exit‖.
global
configuration
mode
quit
disconnect
with switch
VLAN
configuration
mode
Configure
VLAN
parameter
QTECH(config-if-
vlan)#
Input ―vlan 2‖ in
global
configuration
mode, VLAN
configuration
mode can enter
other VLAN mode
and interface
configuration
mode without
inputting ―exit‖.
AAA
configuration
mode
Create
domain
QTECH(config-
aaa)#
Input ―aaa‖ in
global
configuration
mode
RADIUS
configuration
mode
Configure
RADIUS
server
parameter
QTECH(config-
radius-default)#
Input ―radius host
default‖ in global
configuration
mode
end return to
privileged
mode
exit return to
AAA
configuration
mode
quit
disconnect
with switch
Domain
configuration
mode
Configure
domain
parameter
QTECH(config-aaa-
test.com)#
Input ―domain
test.com‖ in AAA
configuration
mode
1.1.2 Command Syntax Comprehension
This chapter describes the steps needed for command configuration. Please read this section
and related detail information of command line interface in the following sections carefully.
