ESIE07-04 General Outline
Part 1 – System Outline 1–91
3
1
4
5
Components The table below lists the components.
No. Component
1 Condenser coil
2Evaporator
3 Evaporator water inlet
4 Evaporator water outlet
5 Victaulic connections for 219.1 O.D. tube
6 Operating and control panel
7 360 x 150 slot for power and control panel connection
8 Compressor enclosure (optional)
9 Coil protection guards (optional)
10 10 isolator mounting holes 25 mm DIA.
11 8 lifting shackles
