The Digital Controller ESIE07-04
2–34 Part 2 – Functional Description
3
1
2
4
5
Unit limiting This screen allows you to enable/disable the unit limiting function.
Unit limiting current
limit / Superv.
current limit
This screen is only visible when current limit or superv. current limit is selected.
This function is only available on SPN units (special request).
Compressor
sequencing
This screen allows you to set the compressors sequencing.
Manual compressor
sequencing
This screen is only visible when manual compressor sequencing is selected.
This screen allows you to set the sequence of the compressors. When selected the sequence is fixed
and the controller will no longer look for the running hours of each compressor.
Possible settings :
P None
P Demand Limit : Unit limiting with external signal
P Current Limit : Only available on SPN unit
P Superv. Demand : Unit limiting with external signal coming from BMS system
P Superv. Current : Unit limiting with external signal coming from BMS system
Unit Limiting
None
4m A
20 mA
Max Curr.
000 A
400 A
300 A
Current Limit Set
Possible settings :
P Auto : Automatic rotation according to the running hours of each compressor
P Manual : Manual set sequence for each compressor stage
Compressors
Sequencing
Auto
Set Compressor Stage
C # 1 1st C # 2 2nd
C # 3 3rd C # 4 4th
