ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–55
3
2
4
5
1
Reset all
parameters to
default values
This screen allows you to reset all parameters to the default values.
EXV settings This screen allows you to enter the EXV setting password.
Manufacturer
settings on control
board # 2
(comp 3 and 4)
If compressor 3 or 4 is present, you can scroll between control board # 1 (comp 1 and 2) and control
board # 2 (comp 3 and 4) with the info button.
When you press the info button, the following screens will appear for control board # 2 in the
manufacturer menu.
P U : 1 : Reset all parameters on control board # 1
P Y : Reset all parameters of this control board to the default values
U : 1
Reset all Parameters
to Default Values N
EXV Setting
Insert Password 0000
P Setpoint : Freeze prevention activation setpoint (for evaporator 2 leaving water)
P Diff : Freeze prevention reset difference
P Time Check : Time that the controller will refresh the RS485 net
P Refresh Y : Start the refreshing of the RS485 net
Freeze Prevent
Setpoint 00.0 ˚C
Diff. 00.0 ˚C
RS485 Net
Time Check 045
Refresh N
