General Outline ESIE07-04

1–20 Part 1 – System Outline

1.9 Technical Specifications: EWAD-BJYNN/Z

Technical

specifications

The table below contains the technical specifications.

Note

(1) Cooling capacity and power input are based on 12/7 °C entering/leaving water temp. and 35°C air ambient

temp.Power input is for compressor only.

Model EWAD-BJYNN/Z

Unit size 600 650 700 850 900 950 C10

Cooling capacity (1) kW 569 631 668 840 914 953 1013

Power input (1) kW 216 237 264 323 336 361 361

COP 2,64 2,66 2,53 2,61 2,72 2,64 2,80

Screw compressors No. 2223333

Refrigerant circuits No. 2223333

Refrigerant charge R-134a kg 124 128 132 186 196 194 204

Oil charge kg 40 40 40 60 60 60 60

Min % of capacity reduction % 12.5 12.5 12.5 8.3 8.3 8.3 8,3

Condenser fans

No. of fans / nominal power fan kW 12/0.3 13/0.3 14/0.3 18/0.3 20/0.3 20/0.3 22/0.3

Fan speed rpm 500 500 500 500 500 500 500

Diameter mm 800 800 800 800 800 800 800

Total air flow m3/s 30.8 33.3 35.9 46.1 51.3 51.3 56.4

Evaporator

Evaporators / water volume No./l 1/254 1/246 1/246 1/415 1/402 1/402 1/402

Max operating pressure bar 10.5 10.5 10.5 10.5 10.5 10.5 10.5

Water connection diameter mm 168.3 168.3 168.3 219.1 219.1 219.1 219.1

Condenser coil

Coil type Lanced fins - internally spiral wound tubes

Weight and dimensions

Standard unit shipping weight kg 5659 5900 6030 8725 9310 9310 9750

Standard unit operating weight kg 5864 6150 6280 9150 9720 9720 10160

Unit length mm 6210 7110 7110 9200 10100 10100 11000

Unit width mm 2230 2230 2230 2230 2230 2230 2230

Unit height mm 2520 2520 2520 2520 2520 2520 2520
