The Digital Controller ESIE07-04
2–58 Part 2 – Functional Description
3
1
2
4
5
EXV type This screen allows you to set the valve type and gas type.
Opening / Closing
extra steps
This screen allows you to enable / disable the extra steps at closing or opening of the expansion valve.
Superheat setpoint This screen allows you to set the superheat setpoint and superheat dead band.
EXV PID factors This screen allows you to set the EXV regulation PID factors.
P Valve Type : Type of valve used in unit
P Gas Type : Refrigerant used in unit
EXV Settings
Value Type
ALCO EX8
Gas Type R134a
P Opening EXTRAs Y : Extra opening pulses are given when fully open position is reached
P Closing EXTRAs Y : Extra closing pulses are given when fully closed position is reached
P Time EXTRAs : Function to be confirmed
EXV Settings
Opening EXTRAs Y
Closing EXTRAs Y
Time EXTRAs 0000 s
P SHeat Setp : Superheat setpoint
P Dead Zone : Dead band around the superheat setpoint
EXV Settings
SHeat Setp. 06.0 ˚C
Dead Zone 00.0 ˚C
EXV Settings
Prop. Factor 80.0
Int. Factor 030 s
Diff. Factor 00.5 s
