General Outline ESIE07-04
1–6 Part 1 – System Outline
3
1
1
4
5
1.2 Technical Specifications: EWAD-BJYNN
Technical
specifications
The table below contains the technical specifications.
Model EWAD-BJYNN
Unit size 650 700 750 850 900
Cooling capacity (1) kW 640 700 761 817 886
Power input (1) kW 217 233 253 270 282
COP 2.94 3.01 3.01 3.03 3.15
Screw compressors N° 2 2 2 2 2
Refrigerant circuits N° 2 2 2 2 2
Refrigerant charge R-134a kg 97 104 114 124 124
Oil charge kg 40 40 40 40 40
Min % of capacity reduction % 12.5 12.5 12.5 12.5 12.5
Condenser fans
No. of fans / nominal power fan kW 9/1.7 10/1.7 11/1.7 12/1.7 12/1.7
Fan speed rpm 860 860 860 860 860
Diameter mm 800 800 800 800 800
Total air flow m3/s 47.5 52.8 58.1 63.3 64.5
Evaporator
Evaporators / water volume N°/l 1/254 1/254 1/246 1/246 1/246
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5
Water connection diameter mm 168.3 168.3 168.3 168.3 168.3
Condenser coil
Coil type Lanced fins - internally spiral wound tubes
Weight and dimensions
Standard unit shipping weight kg 4910 4990 5256 5480 5580
Standard unit operating weight kg 5130 5200 5520 5734 5834
Unit length mm 5310 5310 6210 6210 6210
Unit width mm 2230 2230 2230 2230 2230
Unit height mm 2520 2520 2520 2520 2520
Model EWAD-BJYNN
Unit size Note (2) 950 C10 C11 C12 C13
Cooling capacity (1) kW 988 1057 1109 1166 1226
Power input (1) kW 334 345 369 386 404
COP 2.96 3.06 3.01 3.02 3.04
Screw compressors N° 33333
Refrigerant circuits N° 33333
Refrigerant charge R-134a kg 144 160 164 180 186
Oil charge kg 60 60 60 60 60
Min % of capacity reduction % 8.3 8.3 8.3 8.3 8.3
Condenser fans
No. of fans / nominal power fan kW 14/1.7 16/1.7 16/1.7 18/1.7 18/1.7
Fan speed rpm 860 860 860 860 860
Diameter mm 800 800 800 800 800
Total air flow m3/s 73.9 86.0 84.5 89.7 95.0
Evaporator
Evaporators / water volume N°/l 1/415 1/415 1/402 1/402 1/402
Max operating pressure bar 10.5 10.5 10.5 10.5 10.5
Water connection diameter mm 219.1 219.1 219.1 219.1 219.1
Condenser coil
Coil type Lanced fins - internally spiral wound tubes
