The Digital Controller ESIE07-04
2–42 Part 2 – Functional Description
3
1
2
4
5
If consulting this screen or controller # 2 :
Analog outputs These screens show you the value of the analog outputs (VFD output signal).
Remark : Y1 and Y2 are used only if unit has VFD fans.
Remark : Y4 and Y5 are used only if unit has VFD fans.
Soft load This screen is only visible when soft load function is enabled.
This screen shows you the parameters of the soft load function.
P B9 : O W ev1 : Outlet water temperature of evaporator 1
P B10 : O W ev2 : Outlet water temperature of evaporator 2
P Y1 : Read-out of the VFD output signal of circuit # 1
P Y2 : Read-out of the second VFD output signal of circuit # 1
P Y4 : Read-out of the VFD output signal of circuit # 2
P Y5 : Read-out of the second VFD output signal of circuit # 12
Analog Outputs :
Y1 : 00.0 V
Y2 : 00.0 V
Analog Outputs :
Y4 : 00.0 V
Y5 : 00.0 V
P Soft Load :
Off : Soft load is not active
On : Soft load is active
P Max Stage : Max unit capacity during the soft load function
P Rem. Time : Remaining time that the soft load function is active
P Max Time : Time of the soft load function
Soft Load Off
Max Stage 50 %
Rem. Time 000 min
Max Time 020 min
