ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–31
3
2
4
5
1
Water temperatures If 2 evaporators are present, you can scroll between circuits 1, 2 (evap 1) and circuits 3, 4 (evap 2)
with the info button.
When you press the info button, the following screen will appear, showing the leaving water
temperature of each evaporator:
Comp 3 and 4
information
The following screens will appear for compressor 3 and compressor 4 (if present in the unit)
P Compressor status (see page 2–29)
P Refrigerant pressures (see page 2–29)
P Refrigerant temperatures (see page 2–30)
P Load request (see page 2–30)
P LVG Evap 1 : Leaving water temperature of evaporator 1
P LVG Evap 2 : Leaving water temperature of evaporator 2
Water Temperatures
LVG Evap 1 = 00.0˚C
LVG Evap 2 = 00.0˚C
