Manual Upload or Download Control Test Procedure ESIE07-04
3–48 Part 3 – Troubleshooting
3
1
3
4
5
10.2 Manual Upload or Download Control Test Procedure
Introduction This function must only be used for testing of the unit, e.g. during commissioning or trouble shooting.
Description This function allows setting the compressor to a fixed capacity step, without thermostat control. The
unit is still protected by the normal safeties.
When the unit is near to a safety prevention (LP down, HP down, Freeze-prevention,...) it will skip
manual mode and dontinue in normal operation. This is to prevent the unit from tripping on a safety.
This function can be enabled in the service menu (menu + maintenance).
Please enter digit password to get access to this menu digit.
P Manual load 25 - 100%: this parameter can be changed to the required compressor capacity.
P State OFF: this compressor will be disabled
Auto: the PID function will calculate the needed capacity
Manual: the selected manual load capacity will be used, compressor is fixed to this capacity
Compressor # 1
Manual Load
State
25%
Manual
Compressor # 3
Manual Load
State
25%
Manual
Compressor # 2
Manual Load
State
25%
Manual
Compressor # 4
Manual Load
State
25%
Manual
