The Digital Controller ESIE07-04
2–36 Part 2 – Functional Description
3
1
2
4
5
External alarm This screen allows you to enable/disable the external alarm function.
Time scheduling This screen allows you to enable/disable the time schedule.
This screen allows you to enter the start and stop time of the unit.
This screen allows you to enter the holidays (unit will not operate on these days).
Remark : To enter the date, please enter first the day and second the month. Example : 31/01
P External Alarm :
N : External alarm is disabled
Y : An external alarm signal (open closed contact) can be used to switch off the
unit (external alarm)
P Reset Type :
Auto : When the external alarm signal is reset (closed contact), the controller will
reset and restart the unit.
Manual : When the external alarm signal is reset (closed contact), the controller will
not reset the alarm. A manual reset on the controller is needed to reset the
unit.
Switch Off Unit
On External Alarm Y
Reset Type Auto
P N : Time scheduling is not used
P Y : Time scheduling is enabled, additional screens will appear
Enable Time
Scheduling Y
Start Stop
Mon - Fri 00:00 23:59
Sat 00:00 23:59
Sun 00:00 23:59
Holidays (1) or (2)
00/00 00/00 00/00
00/00 00/00 00/00
00/00 00/000 00/00
