The Digital Controller ESIE07-04
2–60 Part 2 – Functional Description
3
1
2
4
5
High temperature
condensing
protection
This screen allows you to set the high temperature condensing protection setpoints.
Suction
temperature high
limit
This screen allows you to set the suction temperature high limit setpoint.
EXV pressure probe
values
This screen allows you to set the pressure probe minimum and maximum values.
Battery / Plan
setting
These screens allow you to enable / disable the EXV battery and plan.
Change driver
password
This screen allows you to change the driver password.
P HiTcond Limit : Setpoint of the high temperature condensing protection
P Int. Time : Integral time used for the high temperature condensing protection
EXV Settings
HiTcond PROTECTION
HiTcond Limit 90.0 ˚C
Int. Time 04.0 ˚C
EXV Settings
Suction Temperature
High Limit
060.0 ˚C
P Min Value : Minimum value of the low pressure probe operation range
P Max Value : Maximum value of the low pressure probe operation range
EXV Settings
Press. Probe
Min Value –00.5 bar g
Max Value 07.0 bar g
EXV Setting 1
BATTERY PRESENT Y
PLAN PRESENT Y
EXV Setting 2
BATTERY PRESENT Y
PLAN PRESENT Y
Change
Driver
Password
0013
