Daikin EWYT215B-XSA2 [11/75] Electrical options on request
![Daikin EWYT215B-SLA1 [11/75] Electrical options on request](/views2/1677852/page11/bgb.png)
11 | 75
OPTIONS
Hydronic kits Options:
• One centrifugal pump (Low lift) (opt. code 78)
• One centrifugal pump (high lift) (opt. code 79)
• Two centrifugal pump (Low lift) (opt. code 80)
• Two centrifugal pump (high lift) (opt. code 81)
• One centrifugal pump (Low lift) + water tank (opt. code 134)
• One centrifugal pump (high lift) + water tank (opt. code 135)
• Two centrifugal pump (Low lift) + water tank (opt. code 136)
• Two centrifugal pump (high lift) + water tank (opt. code 137)
Unit mounted hydronic kits are available with single and dual pumps.
The Low lift kits provides an average available head of 100 kPa at unit standard conditions. The High lift kits
provides an average available head of 200 kPa at unit standard conditions.
The kit is completed with pressure gauge, safety valve, drain valve. The motor pump is protected by a circuit
breaker installed in control panel. Pump motors are insulation class F, IP55 protected and supplied by the unit
with 400V/3ph/50Hz electric current. The kit is assembled and wired to the control panel.
In case of unit equipped with hydronic kit on board selected to operate with glycol mixture, contact factory.
Water buffer tank volume (if selected), depends on unit model size. For incompatibility refer to the table below:
Option
Description
Incompatibility
78
ONE CENTRIFUGAL PUMP (LOW LIFT)
79 80 81 134 135 136 137 120f 120g 120h 120i 120j 120k 120l
79
ONE CENTRIFUGAL PUMP (HIGH LIFT)
78 80 81 134 135 136 137 120e 120g 120h 120i 120j 120k 120l
80
TWO CENTRIFUGAL PUMP (LOW LIFT)
78 79 81 134 135 136 137 120e 120f 120h 120i 120j 120k 120l
81
TWO CENTRIFUGAL PUMP (HIGH LIFT)
78 79 80 134 135 136 137 120e 120f 120g 120i 120j 120k 120l
134
ONE CENTRIFUGAL PUMP (LOW LIFT) + TANK
03A 78 79 80 81 135 136 137 120e 120f 120g 120h 120j 120k 120l
135
ONE CENTRIFUGAL PUMP (HIGH LIFT) + TANK
03A 78 79 80 81 134 136 137 120e 120f 120g 120h 120i 120k 120l
136
TWO CENTRIFUGAL PUMP (LOW LIFT) + TANK
03A 78 79 80 81 134 135 137 120e 120f 120g 120h 120i 120j 120l
137
TWO CENTRIFUGAL PUMP (HIGH LIFT) + TANK
03A 78 79 80 81 134 135 136 120e 120f 120g 120h 120i 120j 120k
Refrigerant leak detection (opt. code 121 - Available only on units with compressors’ enclosure)
Automated permanent refrigerant leak detection system installed on board. The refrigerant sensors are installed
within the compressor enclosures and are specifically calibrated for R-32 refrigerant. When leaks above a certain
concentration are detected, the sensor provides a signal to the unit controller (a specific alarm is visualized on
the unit microprocessor). The automatic shut down and pump down of refrigerant into the condensing section
occurs on the detection of refrigerant leakage. The alarm threshold that triggers automatic pump down upon
detection of refrigerant is set to a maximum of 500ppm. Available only on units with compressors’ enclosure.
Electrical options – On request
Compressor thermal overload relays (opt. code 11 – Double V Coil units only)
Available on Double V Coil units only. - Opt. incompatibility 95
Under over voltage control (opt. code 15)
Electronic device that monitors and displays input voltage. It stops the unit in case of phase loss, wrong phase
sequence, or voltage exceeding minimum and maximum allowed values.
Energy meter (opt. code 16)
Device installed inside the control box that displays units’ electrical power parameters such as input line voltage
and phase current, input active and reactive power, active and reactive energy. An integrated RS485 module
allows a Modbus communication to an external BMS.
Speedtrol (opt. code 42 – Double V Coil units only)
Opt. incompatibility 99, 99a, 142A, 142B, 160, 160C, 161B
Continuous fan speed regulation on the first fan (VFD driven) of each circuit. It allows unit operation down to
-18ºC (available for standard and low sound version).
Evaporator flow switch (opt. code 58)
Supplied separately to be wired and installed on the Water Side Heat Exchanger water piping (by the customer).
The installation of the flow switch in mandatory.
Compressors circuit breakers (opt. code 95)
