GENERAL CHARACTERISTICS
7 | 75
Additional information related to F-GAS Regulation (EU) No 517/2014 of the
European Parliament and of the Council of 16 April 2014 on fluorinated
greenhouse gases and repealing Regulation (EC) No 842/2006
Unit Model
Refrigerant
type
Refrigerant
GWP
N° of
circuits
Refrigerant
charge
Circuit 1
[kg]
Refrigerant
charge
Circuit 1
[tCO2Eq]
Refrigerant
charge
Circuit 2
[kg]
Refrigerant
charge
Circuit 1
[tCO2Eq]
EWYT085B-SS(L)(R)A1
R32
675
1
11.0
7
EWYT105B-SS(L)(R)A1
R32
675
1
19.0
13
EWYT135B-SS(L)(R)A1
R32
675
1
27.0
18
EWYT175B-SS(L)(R)A1
R32
675
1
27.0
18
EWYT215B-SS(L)(R)A1
R32
675
1
35.0
24
EWYT205B-SS(L)(R)A2
R32
675
2
17.5
12
17.5
12
EWYT235B-SS(L)(R)A2
R32
675
2
21.5
15
21.5
15
EWYT255B-SS(L)(R)A2
R32
675
2
21.5
15
21.5
15
EWYT300B-SS(L)(R)A2
R32
675
2
10.0
7
17.5
12
EWYT340B-SS(L)(R)A2
R32
675
2
21.0
14
21.0
14
EWYT390B-SS(L)(R)A2
R32
675
2
35.5
24
35.5
24
EWYT430B-SS(L)(R)A2
R32
675
2
35.5
24
35.5
24
EWYT490B-SS(L)(R)A2
R32
675
2
35.5
24
35.5
24
EWYT540B-SS(L)(R)A2
R32
675
2
35.5
24
35.5
24
EWYT590B-SS(L)(R)A2
R32
675
2
35.5
24
50.0
34
EWYT630B-SS(L)(R)A2
R32
675
2
50.0
34
50.0
34
Unit Model
Refrigerant
type
Refrigerant
GWP
N° of
circuits
Refrigerant
charge
Circuit 1
[kg]
Refrigerant
charge
Circuit 1
[tCO2Eq]
Refrigerant
charge
Circuit 2
[kg]
Refrigerant
charge
Circuit 1
[tCO2Eq]
EWYT085B-XS(L)(R)A1
R32
675
1
17.0
11
EWYT115B-XS(L)(R)A1
R32
675
1
29.4
20
EWYT135B-XS(L)(R)A1
R32
675
1
29.8
20
EWYT175B-XS(L)(R)A1
R32
675
1
34.5
23
EWYT215B-XS(L)(R)A1
R32
675
1
44.0
30
EWYT215B-XS(L)(R)A2
R32
675
2
25.0
17
25.0
17
EWYT235B-XS(L)(R)A2
R32
675
2
25.0
17
25.0
17
EWYT265B-XS(L)(R)A2
R32
675
2
27.5
19
27.5
19
EWYT310B-XS(L)(R)A2
R32
675
2
35.0
24
35.0
24
EWYT350B-XS(L)(R)A2
R32
675
2
35.0
24
35.0
24
EWYT400B-XS(L)(R)A2
R32
675
2
35.0
24
50.0
34
EWYT440B-XS(L)(R)A2
R32
675
2
50.0
34
50.0
34
EWYT500B-XS(L)(R)A2
R32
675
2
50.0
34
64.5
44
EWYT560B-XS(L)(R)A2
R32
675
2
64.5
44
64.5
44
EWYT600B-XS(L)(R)A2
R32
675
2
64.5
44
79.0
53
EWYT630B-XS(L)(R)A2
R32
675
2
79.0
53
79.0
53
EWYT650B-XS(L)(R)A2
R32
675
2
79.0
53
79.0
53
Note: Equipment contains fluorinated greenhouse gases.
Actual refrigerant charge depends on the final unit construction, details can be found on the unit
labels.
