16 | 75
TECHNICAL SPECIFICATION
EWYT~B-SS
MODEL
EWYT085B-
SSA1
EWYT105B-
SSA1
EWYT135B-
SSA1
EWYT175B-
SSA1
EWYT205B-
SSA2
EWYT215B-
SSA1
COOLING PERFORMANCE
Capacity - Cooling
kW
75
98
120
153
189
193
Capacity control - Type
STEP
STEP
STEP
STEP
STEP
STEP
Capacity control - Minimum
capacity
%
50
38
50
38
19
50
Unit power input - Cooling
kW
28
36.6
44.6
57.8
71.3
72.3
EER
2.69
2.68
2.7
2.65
2.66
2.67
SEER
3.9
3.98
3.9
4.01
3.96
3.9
IPLV
4.43
4.4
4.32
4.28
4.33
4.36
CASING
Colour *
IW
IW
IW
IW
IW
IW
Material *
GPSS
GPSS
GPSS
GPSS
GPSS
GPSS
DIMENSIONS
Height
mm
1800
1800
1800
1800
1800
1800
Width
mm
1195
1195
1195
1195
1195
1195
Length
mm
2225
2825
3425
3425
4350
4025
WEIGHT
Unit Weight
kg
955
1065
1165
1320
1500
1500
Operating Weight
kg
962
1072
1172
1327
1511
1511
WATER HEAT EXCHANGER
Type *
PHE
PHE
PHE
PHE
PHE
PHE
Fluid
Water
Water
Water
Water
Water
Water
Fouling Factor
m2°C/W
0
0
0
0
0
0
Water Volume
l
7
7
7
7
11
11
Water temperature in
°C
12
12
12
12
12
12
Water temperature out
°C
7
7
7
7
7
7
Water flow rate
l/s
3.6
4.7
5.8
7.3
9
9.2
Water pressure drop
kPa
14.9
24.1
35.1
54
45
46.4
Insulation material *
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
AIR HEAT EXCHANGER
Type *
HFP
HFP
HFP
HFP
HFP
HFP
FAN
Type *
DPT
DPT
DPT
DPT
DPT
DPT
Drive *
Phase cut
Phase cut
Phase cut
Phase cut
Phase cut
Phase cut
Diameter
mm
450
450
450
450
450
450
Nominal air flow
l/s
6888
10809
14412
13777
17220
17221
Air Temperature
°C
35
35
35
35
35
35
Quantity
No.
4
6
8
8
10
10
Speed
rpm
1360
1360
1360
1360
1360
1360
Motor input
kW
1.8
2.8
3.7
3.7
4.6
4.6
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge
l
6.5
7.69
8.88
10.7
15.3
12.6
Quantity
No.
2
2
2
2
4
2
SOUND LEVEL**
Sound Power - Cooling
dB(A)
83.8
87.2
89.1
90.8
89.9
92.2
Sound Pressure level@1m
distance - Cooling
dB(A)
66.4
69.4
70.9
72.6
71.2
73.7
REFRIGERANT CIRCUIT
Refrigerant type
R32
R32
R32
R32
R32
R32
Refrigerant charge
kg
11
19
27
27
35
35
N. of circuits
No.
1
1
1
1
2
1
PIPING CONNECTIONS
Evaporator water inlet/outlet
mm
88.9
88.9
88.9
88.9
88.9
88.9
