Daikin EWYT215B-XSA2 [23/75] Technical specification
![Daikin EWYT350B-XLA2 [23/75] Technical specification](/views2/1677852/page23/bg17.png)
23 | 75
TECHNICAL SPECIFICATION
MODEL
EWYT235B-
SRA2
EWYT255B-
SRA2
EWYT300B-
SRA2
EWYT340B-
SRA2
EWYT390B-
SRA2
COOLING PERFORMANCE
Capacity - Cooling
kW
209
226
265
311
344
Capacity control - Type
STEP
STEP
STEP
STEP
STEP
Capacity control - Minimum
capacity
%
17
25
22
19
17
Unit power input - Cooling
kW
80.7
88.8
102
117
131
EER
2.59
2.55
2.59
2.64
2.61
SEER
3.83
3.84
4.18
4.37
4.21
IPLV
4.28
4.26
4.29
4.69
4.58
CASING
Colour *
IW
IW
IW
IW
IW
Material *
GPSS
GPSS
GPSS
GPSS
GPSS
DIMENSIONS
Height
mm
1800
1800
2514
2514
2514
Width
mm
1195
1195
2282
2282
2282
Length
mm
4950
4950
3225
3225
4125
WEIGHT
Unit Weight
kg
1830
1855
2260
2410
3340
Operating Weight
kg
1841
1869
2274
2430
3360
WATER HEAT EXCHANGER
Type *
PHE
PHE
PHE
PHE
PHE
Fluid
Water
Water
Water
Water
Water
Fouling Factor
m2°C/W
0
0
0
0
0
Water Volume
l
11
14
14
20
20
Water temperature in
°C
12
12
12
12
12
Water temperature out
°C
7
7
7
7
7
Water flow rate
l/s
10
10.8
12.7
14.8
16.4
Water pressure drop
kPa
53.5
43.6
58.1
47.6
57
Insulation material *
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
AIR HEAT EXCHANGER
Type *
HFP
HFP
HFP
HFP
HFP
FAN
Type *
DPT
DPT
DPT
DPT
DPT
Drive *
Phase cut
Phase cut
VFD
VFD
VFD
Diameter
mm
450
450
800
800
800
Nominal air flow
l/s
18078
18078
23608
28330
39446
Air Temperature
°C
35
35
35
35
35
Quantity
No.
12
12
5
6
8
Speed
rpm
1200
1200
780
780
780
Motor input
kW
5
5
5.5
6.6
8.7
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge
l
16.5
17.7
19.6
21.4
23.3
Quantity
No.
4
4
4
4
4
SOUND LEVEL**
Sound Power - Cooling
dB(A)
85.5
86.3
87.2
88.0
89.2
Sound Pressure level@1m
distance - Cooling
dB(A)
66.5
67.3
67.7
68.5
69.2
REFRIGERANT CIRCUIT
Refrigerant type
R32
R32
R32
R32
R32
Refrigerant charge
kg
43
43
27.5
42
71
N. of circuits
No.
2
2
2
2
2
PIPING CONNECTIONS
Evaporator water inlet/outlet
mm
88.9
88.9
88.9
88.9
88.9
