Daikin EWYT215B-XSA2 [18/75] Technical specification
![Daikin EWYT115B-XSA1 [18/75] Technical specification](/views2/1677852/page18/bg12.png)
18 | 75
TECHNICAL SPECIFICATION
MODEL
EWYT430B-
SSA2
EWYT490B-
SSA2
EWYT540B-
SSA2
EWYT590B-
SSA2
EWYT630B-
SSA2
COOLING PERFORMANCE
Capacity - Cooling
kW
375
434
482
531
570
Capacity control - Type
Step
Step
Step
Step
Step
Capacity control - Minimum
capacity
%
25
22
19
18
17
Unit power input - Cooling
kW
147
171
192
206
219
EER
2.55
2.54
2.51
2.57
2.6
SEER
4
4.23
4.23
4.17
4.25
IPLV
4.31
4.46
4.52
4.44
4.53
CASING
Colour *
IW
IW
IW
IW
IW
Material *
GPSS
GPSS
GPSS
GPSS
GPSS
DIMENSIONS
Height
mm
2514
2514
2514
2514
2514
Width
mm
2282
2282
2282
2282
2282
Length
mm
4125
4125
4125
5025
5025
WEIGHT
Unit Weight
kg
3190
3180
3370
4267
4267
Operating Weight
kg
3210
3207
3397
4302
4308
WATER HEAT EXCHANGER
Type *
PHE
PHE
PHE
PHE
PHE
Fluid
Water
Water
Water
Water
Water
Fouling Factor
m2°C/W
0
0
0
0
0
Water Volume
l
20
27
27
35
41
Water temperature in
°C
12
12
12
12
12
Water temperature out
°C
7
7
7
7
7
Water flow rate
l/s
17.9
20.7
23
25.3
27.2
Water pressure drop
kPa
66.7
58.7
71.2
58.3
66.1
Insulation material *
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
AIR HEAT EXCHANGER
Type *
HFP
HFP
HFP
HFP
HFP
FAN
Type *
DPT
DPT
DPT
DPT
DPT
Drive *
On/Off
On/Off
On/Off
On/Off
On/Off
Diameter
mm
800
800
800
800
800
Nominal air flow
l/s
46854
45830
44806
57288
56008
Air Temperature
°C
35
35
35
35
35
Quantity
No.
8
8
8
10
10
Speed
rpm
900
900
900
900
900
Motor input
kW
13.9
13.9
13.9
17.4
17.4
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge
l
25.2
29.6
34
35.9
37.8
Quantity
No.
4
5
6
6
6
SOUND LEVEL**
Sound Power - Cooling
dB(A)
96.3
96.6
96.8
97.5
97.8
Sound Pressure level@1m
distance - Cooling
dB(A)
76.3
76.6
76.8
77.1
77.4
REFRIGERANT CIRCUIT
Refrigerant type
R32
R32
R32
R32
R32
Refrigerant charge
kg
71
71
71
85.5
100
N. of circuits
No.
2
2
2
2
2
PIPING CONNECTIONS
Evaporator water inlet/outlet
mm
88.9
88.9
88.9
88.9
88.9
