TECHNICAL SPECIFICATION
EWYT~B-XR
MODEL
EWYT0855B-
XRA1
EWYT115B-
XRA1
EWYT135B-
XRA1
EWYT175B-
XRA1
EWYT215B-
XRA1
EWYT215B-
XRA2
COOLING
PERFORMANCE
Capacity - Cooling
kW
79
103
124
164
203
204
Capacity control -
Type
STEP
STEP
STEP
STEP
STEP
STEP
Capacity control -
Minimum capacity
%
50
38
50
38
50
19
Unit power input -
Cooling
kW
26.6
35.4
42.6
57.4
72.9
68.8
EER
2.98
2.9
2.92
2.86
2.79
2.97
SEER
4.21
4.37
4.21
4.41
4.16
4.42
IPLV
4.73
4.73
4.67
4.65
4.67
4.86
CASING
Colour *
IW
IW
IW
IW
IW
IW
Material *
GPSS
GPSS
GPSS
GPSS
GPSS
GPSS
DIMENSIONS
Height
mm
1800
1800
1800
1800
1800
1800
Width
mm
1195
1195
1195
1195
1195
1195
Length
mm
2825
3425
3425
4025
4625
5550
WEIGHT
Unit Weight
kg
1110
1170
1250
1430
1610
2030
Operating Weight
kg
1121
1181
1261
1446
1626
2065
WATER HEAT
EXCHANGER
Type *
PHE
PHE
PHE
PHE
PHE
PHE
Fluid
Water
Water
Water
Water
Water
Water
Fouling Factor
m2°C/W
0
0
0
0
0
0
Water Volume
l
11
11
11
16
16
35
Water temperature in
°C
12
12
12
12
12
12
Water temperature
out
°C
7
7
7
7
7
7
Water flow rate
l/s
3.8
4.9
5.9
7.8
9.7
9.7
Water pressure drop
kPa
9.33
14.9
21.1
19.6
28.9
11.8
Insulation material *
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
Closed Cell
AIR HEAT
EXCHANGER
Type *
HFP
HFP
HFP
HFP
HFP
HFP
FAN
Type *
DPT
DPT
DPT
DPT
DPT
DPT
Drive *
Phase cut
Phase cut
Phase cut
Phase cut
Phase cut
Phase cut
Diameter
mm
450
450
450
450
450
450
Nominal air flow
l/s
8298
11630
11064
13830
16596
19362
Air Temperature
°C
35
35
35
35
35
35
Quantity
No.
6
8
8
10
12
14
Speed
rpm
1108
1108
1108
1108
1108
1108
Motor input
kW
2.4
3.2
3.2
4
4.7
5.5
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge
l
6.5
7.69
8.88
10.7
12.6
15.3
Quantity
No.
2
2
2
2
2
4
SOUND LEVEL**
Sound Power -
Cooling
dB(A)
77.1
81.0
82.9
85.1
86.5
83.9
Sound Pressure
level@1m distance -
Cooling
dB(A)
59.3
62.8
64.7
66.6
67.7
64.6
REFRIGERANT
CIRCUIT
Refrigerant type
R32
R32
R32
R32
R32
R32
Refrigerant charge
kg
17
29.4
29.8
34.5
44
50
N. of circuits
No.
1
1
1
1
1
2
PIPING
CONNECTIONS
Evaporator water
inlet/outlet
mm
88.9
88.9
88.9
88.9
88.9
88.9
