Daikin EWYT215B-XSA2 [12/75] Options
![Daikin EWYT400B-XSA2-VFDFAN [12/75] Options](/views2/1677852/page12/bgc.png)
12 | 75
OPTIONS
Safety devices that include in a single device all safety functions otherwise provided by standard fuses and
optional thermal relays, such as protection against overcurrent, overload, current unbalance
Opt. incompatibility 11
Fans speed regulation (opt. code 99 and 99a)
Fans speed regulation: continuous modulation of the fans’ speed for optimal condensation control at low ambient
temperatures.
Fans silent mode: This feature allows the user to set up customized time bands to reduced fans’ speed rotation
and therefore sound emission in those areas where quiet is a mandatory requirement during specific time of the
day (e.g. night operation).
Note: option 99 is standard on Parallel Coil units (phase cut). - Opt. incompatibility 42, 142B, 160C, 161B
Note: option 99a is standard on Double V Coil V units reduced sound (inverter). - Opt. incompatibility 42, 96,,
142A 142B, 160, 160C, 161B.
Ground fault relay (opt. code 102 – Double V Coil units only)
To shut down the unit in case of a ground fault condition is detected.
Nordic kit (opt. 114)
This option is offering enhanced drain pans and water discharge line, electric heaters on the pans protected by
insulating material and additional covers for plugs at the back side of the electrical panel. Recommended for
cold regions installations.
HIGH AMBIENT KIT (OP. code 142A) - OP. incompatibility 42 99a 142B 142C 160 160B 160C 161B
The high ambient kit allows to increase the maximum operating ambient temperature for all the Parallel Coil
units. Minimum ambient temperature in Cooling is -10°C. Check the unit operating envelope and CSS for more
information.
HIGH AMBIENT KIT (OPERATION ABOVE 46°C ON-OFF FANS) (OP. code 142B)
OP. incompatibility 42 99 99a 142A 142C 160 160B 160C 161B
The high ambient kit allows to increase the maximum operating ambient temperature for all the Double V Coil
units, with Standard and Low Sound Configurations.
Minimum ambient temperature in Cooling is +10°C. Check the unit operating envelope and CSS for more
information.
HIGH AMBIENT KIT (OPERATION ABOVE 46°C BRUSHLESS FANS) (OP. code 142C)
OP. incompatibility 42 99 99a 142A 142B 160 160B 160C 161B
The high ambient kit allows to increase the maximum operating ambient temperature for all the Double V Coil
units, with Reduced Sound Configuration.
Minimum ambient temperature in Cooling is -18°C. Check the unit operating envelope and CSS for more
information.
VERSION
HIGH AMBIENT KIT
HIGH AMBIENT KIT
PARALLEL COIL LAYOUT
SS/SL
OP.142A
NA
PARALLEL COIL LAYOUT
SR
OP.142A
NA
PARALLEL COIL LAYOUT
XS/XL
OP.142A
NA
PARALLEL COIL LAYOUT
XR
OP.142A
NA
VERSION
HIGH AMBIENT KIT
HIGH AMBIENT KIT
DOUBLE V COIL LAYOUT
SS/SL
NA
OP.142B
DOUBLE V COIL LAYOUT
SR
NA
OP.142C
DOUBLE V COIL LAYOUT
XS/XL
NA
OP.142B
DOUBLE V COIL LAYOUT
XR
NA
OP.142C
100 PA ESP FANS (OP. code 160 – Parallel Coil units only)
OP. incompatibility 99a 42 142A 142B 142C 160B 160C 161B
Special ON/OFF fans providing 100 Pa ESP. The envelope doesn’t change if the option is selected. Check the CSS
for more information.
