2.2 Board Arrangement
No. Item
1
EP2C612D8HM
2
Rear Expander 24bay BP
3
Front Expander 24bay BP
4
Middle plane BP
5
PDB
6
LED board
7
2port 2.5” OS BP
8
Switch board (front)
9
HDD BP-top daughter board
10
HDD BP-down daughter board
11
Interposer BP
12
Riser Card (L)
13
Riser Card (R)
14
Riser Card
