4U100 Series
28 29
English
3.7 Motherboard
Attention! DO NOT open the motherboard tray if the server is not powered down or while
it is still running.
Replacing the Motherboard
You must remove all connected cables from the motherboard to avoid damaging the
motherboard and its components when you remove it later.
1. Press the lever toward the handle and pull out the motherboard tray.
2. Loosen the screws to remove the tray cover and the riser-card bracket.
