4U100 Series
18 19
English
Installing a 3.5” Hard Drive into the Chassis
1. Carefully align and place the hard drive into the tray.
2. Gently slide the HDD tray into the chassis evenly.
3. Push the tray downwards until it is rmly seated and locks into place.
2
3
1
