ASRock 4U100-C612 [17/42] English

12 13

English

Power Button

Press the power switch button to toggle the system power on and o.

To remove all power from the system completely, disconnect the power cord from the

server.

ID Button

Press the ID button to toggle the front panel ID LED and the baseboard ID LED on and

o. You are able to locate the server you’re working on from behind a rack of servers.

System Reset Button

When the system is completely unresponsive, press the system reset button to reboot the

server without shutting it o and initialize the system.

Status LED Denitions

Power LED

Status Description

Green Power on

O Power o

ID LED

Status Description

Blue System identication is active.

O System identication is disabled.

LAN1, LAN2 LEDs

Status Description

Green Link between system and network or no access

Blinking Green Network access

HDD Activity LED

Status Description

Blinking Green HDD access

O HDD idle

Global Failure Inducator / System Event LED

Status Description

O Running or normal operation

Red At least one sensor has critical alert
