22 23
English
3.4 Add-on Card
Installing the Add-on Card in the Chassis
Please remove the motherboard tray before the following installation. Refer to the section
enttitle "Motherboard Tray" for more instructions.
1. Release the screws securing the cover to the motherboard tray.
2. Slide the cover toward the rear of the tray. en, li the cover o the tray.
3. Release the screws securing the two riser card aseemblies.
4. Remove the le riser card aseembly rst and then the other one.
Before installing the add-on card, power o the server and unplug the power cord.
1
2
3
3
3
3
4
Riser Card Assembly (Right)
Riser Card Assembly (Left)
