3.1 Server Top Cover
Removing the Server Top Cover
1. Push the cover latch button to release the latch handle.
2. Remove the eight screws that secure the top cover to the chassis.
3. Li the chassis top cover o the chassis.
1
2
2
2
2
3
1. Before removing the top covers, power o the server and unplug the power cord.
2. e system must be operated with all the chassis top covers installed to ensure proper cooling.
