Alert Policies: Click the Alert Policies section to configure the alert policies in the

available slots.

Alert Policies Page

Policy Group Number: Displays the Policy number of the configuration.

Enable this alert: Check the box to enable the policy settings.

Policy Action: Choose any one of the Policy set values from the list.

LAN Channel: Choose a particular channel from the available channel list.

Destination Selector: Choose a particular destination from the configured

destination list.

Event Specific Alert String: Check the box to specify event-specific Alert String.

Alert String Key: Specify which string is to be sent for this Alert Policy entry.

3.8.8.3 LAN Destinations

This page is used to configure the LAN destination of PEF configuration.

LAN Destinations Page
