Launch Java KVM: Click the button to open Java KVM application.

3.10 Image Redirection

This page is used to configure the images into BMC for redirection.

Image Redirection Page

3.10.1 Remote Media

This page is used to configure the remote images into BMC for redirection.

Remote Media Page

Media Type: Displays type of Media such as CD/DVD, Floppy and Hard-disk.

Media Instance: Displays total media instance count.

Image Name: Displays the default recovery image name on the server.

Status: Displays the status of the media.

Session Index: Displays Media Server Session Index.
