Troubleshooting by Remote Controller Si34-704
192 Troubleshooting
Outdoor Unit LA 999Malfunction of power unit —
LC 999Malfunction of transmission between inverter and
control PC board
257
P1 999Inverter over-ripple protection 260
P4 999Malfunction of inverter radiating fin temperature rise
sensor
261
PJ 999Faulty field setting after replacing main PC board or
faulty combination of PC board
263
System U0 879Gas shortage alert 264
U1 999Reverse phase / open phase 266
U2 999Power supply insufficient or instantaneous failure 267
U3 999Check operation is not completed. 270
U3 879Check operation is not completed. 270
U4 999Malfunction of transmission between indoor and
outdoor units
271
U5 999Malfunction of transmission between remote
controller and indoor unit
274
U5 787Failure of remote controller PC board or setting
during control by remote controller
274
U7 999Malfunction of transmission between outdoor units 275
U8 997Malfunction of transmission between main and sub
remote controllers (malfunction of sub remote controller)
281
U9 999Malfunction of transmission between indoor unit and
outdoor unit in the same system
282
UA 999Improper combination of indoor and outdoor units,
indoor units and remote controller
283
UC 888Address duplication of central remote controller 286
UE 999Malfunction of transmission between central remote
controller and indoor unit
287
UF 999Refrigerant system not set, incompatible wiring /
piping
290
UH 999Malfunction of system, refrigerant system address
undefined
291
Central
Remote
Controller
and
Schedule
Timer
M1 8 or 79 9Central remote controller PC board defect
Schedule timer PC board defect
293
M8 8 or 79 9Malfunction of transmission between optional
controllers for centralized control
294
MA 8 or 79 9Improper combination of optional controllers for
centralized control
295
MC 8 or 79 9Address duplication, improper setting 297
Heat
Reclaim
Ventilation
64 879Indoor unit’s air thermistor error —
65 879Outside air thermistor error —
6A 879Damper system alarm —
6A 999Damper system + thermistor error —
6F 879Malfunction of simple remote controller —
6H 879Malfunction of door switch or connector —
94 999Internal transmission error —
