Si34-704 Troubleshooting by Indication on the Remote Controller
Troubleshooting 243
3.31
“
JA
”
Outdoor Unit: Malfunction of High Pressure Sensor
Remote
Controller
Display
JA
Applicable
Models
RXQ5P~54P
Method of
Malfunction
Detection
Malfunction is detected from the pressure detected by the high pressure sensor.
Malfunction
Decision
Conditions
When the high pressure sensor is short circuit or open circuit.
(Not less than 4.22MPa, or 0.01MPa and below)
Supposed
Causes
Defect of high pressure sensor system
Connection of low pressure sensor with wrong connection.
Defect of outdoor unit PC board.
Defective connection of high pressure sensor
Troubleshooting
(V2806)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
∗1: Pressure sensor subject to malfunction code
Malfunction code
JA High pressure sensor S1NPH
Electric symbolPressure sensor subject to malfunction code
Replace the main PCB.
Replace the high pressure sensor.
YES
NO
Replace the main PCB.
NO
Replace the high pressure sensor.
YES
NO
Are the
characteristics of
the high pressure sensor
normal? (Make a comparison
between the voltage characteristics
(∗2) and the gauge
pressure.)
YES
If the
PCB pressure
detection normal?
(Make a comparison between the
checker pressure data and the
voltage characteristics
(∗2).)
1.Set the high pressure gauge
upright.
2.Connect the checker for
VRV to the gauge.
Reset the operation, and then
restart the outdoor unit.
Are the
characteristics of the high
pressure sensor
normal?
