SiBE34-802 Troubleshooting by Remote Controller
Troubleshooting 137
Outdoor Unit LA 9 Malfunction of power unit —
LC 9 Malfunction of transmission between inverter and control PC board 187
P1 9 High voltage of capacitor in main inverter circuit. 188
System
U0 8 Low pressure drop due to refrigerant shortage or electronic expansion
valve failure
189
U1 9 Reverse phase / open phase —
U2 9 Power supply insufficient or instantaneous failure 191
U3 9 Check operation is not completed. 193
U4 9 Malfunction of transmission between indoor and outdoor units 194
U5 9 Malfunction of transmission between remote controller and indoor unit 196
U5 7 Failure of remote controller PC board or setting during control by remote
controller
196
U7 9 Malfunction of transmission between outdoor units —
U8 9 Malfunction of transmission between main and sub remote controllers
(malfunction of sub remote controller)
197
U9 9 Malfunction of transmission between indoor unit and outdoor unit in the
same system
198
UA 9 Excessive number of indoor units 200
UC 8 Address duplication of central remote controller 201
UE 9 Malfunction of transmission between central remote controller and indoor
unit
202
UF 9 System is not set yet 204
UH 9 Malfunction of system, refrigerant system address undefined 205
Central
Remote
Controller
and
Schedule
Timer
UE 9 Malfunction of transmission between centralized remote controller and
indoor unit
206
M1 8 or 7 PC board defect 207
M8 8 or 7 Malfunction of transmission between optional controllers for centralized
control
208
MA 8 or 7 Improper combination of optional controllers for centralized control 209
MC 8 or 7 Address duplication, improper setting 211
Heat
Reclaim
Ventilation
64 8 Indoor unit’s air thermistor error —
65 8 Outside air thermistor error —
68 8 Malfunction of HVU —
6A 8 Damper system alarm —
6A 9 Damper system + thermistor error —
6F 8 Malfunction of simple remote controller —
94 9 Internal transmission error —
8: ON 7: OFF 9: Blink
Malfunction
code
Operation
lamp
Malfunction contents Page
Referred
The system operates for malfunction codes indicated in black squares, however, be sure to check and repair.
