SiBE34-802 Specifications
Specifications 21
Ceiling Mounted Duct Type
1-1 TECHNICAL SPECIFICATIONS FXMQ40PVE FXMQ50PVE FXMQ63PVE FXMQ80PVE FXMQ100PVE FXMQ125PVE
Capacity
Cooling kW 4.5 5.6 7.1 9.0 11.2 14.0
Heating kW 5.0 6.3 8.0 10.0 12.5 16.0
Power Input
Cooling kW
0.194 (1)
0.193 (2)
0.215 (1)
0.214 (2)
0.230 (1)
0.229 (2)
0.298 (1)
0.297 (2)
0.376 (1)
0.375 (2)
0.461 (1)
0.460 (2)
Heating kW 0.182 0.203 0.218 0.286 0.364 0.449
Casing Material Galvanised steel plate
Dimensions Unit
Height mm 300 300 300 300 300 300
Width mm 700 1,000 1,000 1,000 1,400 1,400
Depth mm 700 700 700 700 700 700
Weight Unit kg 28 36 36 36 46 46
Heat
Exchanger
Dimensions
Nr of Rows 3 3 3 3 3 3
Fin Pitch
mm 1.75 1.75 1.75 1.75 1.75 1.75
Face Area
m² 0.148 0.249 0.249 0.249 0.383 0.383
Nr of Stages 16 16 16 16 16 16
Fan Type Sirocco fan
Air Flow Rate Cooling
High high
m³/min 16 18 19.5 25 32 39
High m³/min 13 16.5 17.5 22.5 27 33
Low m³/min 11 15 16 20 23 28
Fan
External static
pressure
High Pa 160 200 200 200 200 200
Standard
Pa 100 100 100 100 100 100
Low Pa 30 50 50 50 50 50
Motor
Output
(high)
W 140 350 350 350 350 350
Drive Direct drive
Piping
connections
Liquid (OD)
Type Flare connection
Diameter
mm 6.35 9.52 9.52 9.52 9.52 9.52
Gas
Type Flare connection
Diameter
mm 12.7 15.9 15.9 15.9 15.9 15.9
Drain
Diameter
mm VP25 (I.D. 32/O.D. 25)
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices Fuse, Fan driver overload protector
Standard Accessories
Operation manual, Installation manual, Drain hose, Sealing pads, Clamps, Washer, Screws, Insulation for fitting,
Clamp metal, Air discharge flange, Air suction flange
Notes
Nominal cooling capacities are based on following conditions: return air temperature: 27°CDB/19°CWB; outdoor
temperature: 35°CDB; standard external static pressure: 100Pa; equivalent refrigerant piping: 7.5m (horizontal)
Nominal heating capacities are based on following conditions: return air temperature: 20°CDB; outdoor temperature:
7°CDB/6°CWB; standard external static pressure: 100Pa; equivalent refrigerant piping: 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
External static pressure is changeable in 13 or 14 stages within the ( ) range by the remote control.
Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its colorimetric
method(gravity method) 50% or more.
