Specifications SiBE34-802
14 Specifications
Ceiling Mounted Cassette Type (Round-flow)
1-1 TECHNICAL SPECIFICATIONS FXFQ63P7VEB FXFQ80P7VEB FXFQ100P7VEB FXFQ125P7VEB
Capacity
Cooling kW 7.1 9.0 11.2 14.0
Heating kW 8.0 10.0 12.5 16.0
Power Input
Cooling kW 0.095 0.120 0.173 0.258
Heating kW 0.114 0.108 0.176 0.246
Casing Material Galvanised steel
Dimensions
Packing
Height mm 220 262 262 304
Width mm 882 882 882 882
Depth mm 882 882 882 882
Unit
Height mm 204 246 246 288
Width mm 840 840 840 840
Depth mm 840 840 840 840
Weight
Unit kg 21.0 24.0 24.0 26.0
Packed Unit kg 26.0 28.0 28.0 31.0
Dimensions Length
Inside mm 2,096
Outside mm 2,152
Heat
Exchanger
Dimensions
Nr of Rows 2 2 2 2
Fin Pitch
mm 1.2 1.2 1.2 1.2
Nr of Passes 7 9 9 11
Face Area
m² 0.357 0.446 0.446 0.535
Nr of Stages 8 10 10 12
Fin Fin type Cross fin coil (Multi louver fins and Hi-XSS tubes)
Fan
Type Turbo fan
Quantity 1 1 1 1
Air Flow Rate
Cooling
High m³/min 16.5 23.5 26.5 33.0
Low m³/min 11.0 14.5 17.0 20.0
Heating
High m³/min 17.5 23.5 28.0 33.0
Low m³/min 12.0 14.5 17.5 20.0
Fan Motor
Model QTS48D11M QTS48C15M QTS48C15M QTS48C15M
Steps 2 2 2 2
Output
(high)
W 56 120 120 120
Refrigerant Name R-410A
Sound Level Cooling
Sound
power
(nominal)
dBA52555861
Cooling
Sound
Pressure
High dBA 34 38 41 44
Low dBA 29 32 33 34
Heating
Sound
Pressure
High dBA 36 38 42 44
Low dBA 30 32 34 34
Piping
connections
Liquid (OD)
Type Flare connection
Diameter
mm 9.5 9.5 9.5 9.5
Gas
Type Flare connection
Diameter
mm 15.9 15.9 15.9 15.9
Drain
Diameter
mm VP25 (I.D. 25/O.D. 32)
Heat Insulation Foamed polystyrene/polyethylene
Sound absorbing insulation (Foamed Polyurethane)
Decoration
Panel
Model BYCQ140CW1
Colour RAL9010
Dimensions
Height mm 50 50 50 50
Width mm 950 950 950 950
Depth mm 950 950 950 950
Weight kg 5.5 5.5 5.5 5.5
Air Filter Resin net with mold resistance
Standard Accessories
Installation and operation manual, Drain hose, Washer for hanging bracket, Screws, Sealing Pads, Insulation for fitting,
Clamp for drain hose, Installation guide, Drain sealing pad
Notes
The sound pressure values are mentioned for a unit installed with rear suction
The sound power level is an absolute value indicating the power wich a sound source generates.
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
