Specifications SiBE34-802
12 Specifications
Ceiling Mounted Cassette Type (Double Flow)
1-1 TECHNICAL SPECIFICATIONS FXCQ63M8V3B FXCQ80M8V3B FXCQ125M8V3B
Nominal
Capacity
Cooling kW 7.10 9.00 14.00
Heating kW 8.00 10.00 16.00
Power input
(Nominal)
Cooling kW 0.161 0.209 0.256
Heating kW 0.126 0.176 0.223
Casing
Colour Non painted
Material Galvanised steel
Dimensions
Packing
Height mm 405 405 405
Width mm 1460 1808 1808
Depth mm 665 645 645
Unit
Height mm 305 305 305
Width mm 1180 1670 1670
Depth mm 600 600 600
Weight
Unit kg 35 47 48
Packed Unit kg 42 55 56
Required Ceiling Void mm 350 350 350
Heat
Exchanger
Dimensions
Length mm 875×2 1365 1365
Nr of Rows 2×2
Fin Pitch
mm 1.50 1.50 1.50
Nr of Passes 6×2 5×2 6
Face Area
m² 0.184×2 0.287×2 0.287×2
Nr of Stages 10×2
Empty Tubeplate
Hole
8
Tube type Hi-XSS (7)
Fin
Fin type Symmetric waffle louvre
Treatment Hydrophilic
Fan
Type Sirocco fan
Quantity 2 3 3
Air Flow Rate
Cooling
High m³/min 16.5 26.0 33.0
Low m³/min 13.0 21.0 25.0
Heating
High m³/min 16.5 26.0 33.0
Low m³/min 13.0 21.0 25.0
Fan Motor
Quantity 1 1 1
Steps Phase cut control
Output
(high)
W305085
Drive Direct drive
Refrigerant Name R-410A
Sound Level Cooling
Sound
power
(nominal)
dBA 52.0 54.0 60.0
Cooling
Sound
Pressure
High dBA 38.0 40.0 45.0
Low dBA 33.0 35.0 39.0
Heating
Sound
Pressure
High dBA 38.0 40.0 45.0
Low dBA 33.0 35.0 39.0
Piping
connections
Liquid (OD)
Type Flare connection
Diameter
mm 9.5 9.5 9.5
Gas
Type Flare connection
Diameter
mm 15.9 15.9 15.9
Drain
Diameter
mm 32 32 32
Heat Insulation Both liquid and gas pipes
Decoration
Panel
Model BYBC63GJW1 BYBC125GJW1 BYBC125GJW1
Colour White (10Y9/0,5)
Dimensions
Height mm 53 53 53
Width mm 1430 1920 1920
Depth mm 680 680 680
Weight kg 9.5 12.0 12.0
Drain-up Height mm 600 600 600
Air Filter Resin net with mold resistance
Air direction control Up and downwards
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices
PC board fuse, Fan motor thermal fuse,
Drain pump fuse
PC board fuse, Fan motor thermal protector, Drain pump fuse
Standard Accessories
Screws for fixing the paper pattern for installation, Washer for hanging bracket, Clamps, Installation and operation manual,
Paper pattern for installation, Insulation for fitting, Drain hose
Notes
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 8m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 8m, level difference : 0m.
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
