SiBE34-802 Specifications
Specifications 27
BEV Units
11-1-1Technical Specifications BEVQ71MAVE BEVQ100MAVE BEVQ125MAVE
Power input
(Nominal)
Cooling kW 0.189 0.298 0.298
Heating kW 0.169 0.278 0.278
Casing Material Galvanised steel plate
Dimensions Packing
Height mm 100 100 100
Width mm 350 350 350
Depth mm 225 225 225
Sound absorbing thermal insulation material Flame and heat resistant foamed polyetherene
Weight Unit kg 3.0 3.0 3.5
Indoor Units
Liquid (OD)
Type Flare connection
Diameter
mm 9.5 9.5 9.5
Gas
Type Flare connection
Diameter
mm 15.9 15.9 15.9
Outdoor Unit
Liquid (OD)
Type Flare connection
Diameter
mm 9.5 9.5 9.5
Suction gas
(OD)
Type Flare connection
Diameter
mm 15.9 15.9 15.9
Standard
Accessories
Item Installation manual, Gas piping connections, Insulation for fitting, Sealing material, Clamps
