SiBE34-802 Specifications
Specifications 19
Ceiling Mounted Built-in Type
1-1 TECHNICAL SPECIFICATIONS FXSQ20M8V3B FXSQ25M8V3B FXSQ32M8V3B FXSQ40M8V3B FXSQ50M8V3B
Capacity
(Conditions
specified in 1)
Cooling kW 2.20 2.80 3.60 4.50 5.60
Heating kW 2.50 3.20 4.00 5.00 6.30
Power input
(Nominal)
Cooling kW 0.110 0.110 0.114 0.127 0.143
Heating kW 0.090 0.090 0.094 0.107 0.123
Casing
Colour Non painted
Material Galvanised steel
Dimensions
Packing
Height mm 354 354 354 354 354
Width mm 742 742 742 892 892
Depth mm 936 936 936 936 936
Unit
Height mm 300 300 300 300 300
Width mm 550 550 550 700 700
Depth mm 800 800 800 800 800
Weight
Unit kg 30 30 30 30 31
Packed Unit kg 34 34 34 34 35
Required Ceiling Void mm 350 350 350 350 350
Heat
Exchanger
Dimensions
Length mm 300 300 300 450 450
Nr of Rows 3 3 3 3 3
Fin Pitch
mm 1.75 1.75 1.75 1.75 1.75
Nr of Passes 3 3 3 4 4
Face Area
m² 0.088 0.088 0.088 0.132 0.132
Nr of Stages 14 14 14 14 14
Empty Tubeplate Hole
14
Tube type Hi-XSS (7)
Fin
Fin type Symmetric waffle louvre
Treatment Hydrophilic
Fan
Type Sirocco fan
Quantity 11111
Air Flow Rate
Cooling
High m³/min 9.00 9.00 9.50 11.50 15.00
Low m³/min 6.50 6.50 7.00 9.00 11.00
Heating
High m³/min 9.00 9.00 9.50 11.50 15.00
Low m³/min 6.50 6.50 7.00 9.00 11.00
Fan
External static
pressure
High Pa 125 125 104 116 136
Standard
Pa 105 105 88 98 114
Low Pa 96 96 78 85 99
Motor
Quantity11111
Model D18H3AA1V1 D18H3AA1V1 D18H3AA1V1 D18H2AC1V1 D18H2AB1V1
Steps step motor
Output
(high)
W5050506585
Drive Direct drive
Refrigerant Name R-410A
Sound Level Cooling
Sound
power
(nominal)
dBA 50.0 50.0 51.0 56.0 58.0
Cooling
Sound
Pressure
High dBA 32.0 32.0 33.0 33.0 35.0
Low dBA 28.0 28.0 28.0 29.0 31.0
Heating
Sound
Pressure
High dBA 32.0 32.0 33.0 33.0 35.0
Low dBA 28.0 28.0 28.0 29.0 31.0
Piping
connections
Liquid (OD)
Type Flare connection
Diameter
mm 6.35 6.35 6.35 6.35 6.35
Gas
Type Flare connection
Diameter
mm 12.7 12.7 12.7 12.7 12.7
Drain
Diameter
mm 32 32 32 32 32
Heat Insulation Both liquid and gas pipes
Decoration
Panel
Model BYBS32DJW1 BYBS32DJW1 BYBS32DJW1 BYBS45DJW1 BYBS45DJW1
Colour White (10Y9/0,5)
Dimensions
Height mm 55 55 55 55 55
Width mm 650 650 650 800 800
Depth mm 500 500 500 500 500
Weight kg 3 3 3 3.5 3.5
Drain-up Height mm 600 600 600 600 600
Air Filter Resin net with mold resistance
Air direction control Up and downwards
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse, Drain pump fuse, Fan motor thermal fuse
Standard Accessories
Metal clamp for drain hose, Paper pattern for installation, Drain hose, Insulation for fitting, Washer for hanger bracket,
Screws for duct flanges, Screws for fixing the paper pattern for installation, Fuse, Installation and operation manual
Notes
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 8m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 8m, level difference : 0m.
The external static pressure is changeable : change the connectors inside the electrical box, this pressure means :
High static pressure -standard - low static pressure
The external static pressure is changeable : change the connectors inside the electrical box, this pressure means :
High static pressure -standard
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
The sound pressure values are mentioned for a unit installed with rear suction
