Specifications SiBE34-802
16 Specifications
Ceiling Mounted Cassette Corner Type
1-1 TECHNICAL SPECIFICATIONS FXKQ25MAVE FXKQ32MAVE FXKQ40MAVE FXKQ63MAVE
Nominal
Capacity
Cooling kW 2.80 3.60 4.50 7.10
Heating kW 3.20 4.00 5.00 8.00
Power input
(Nominal)
Cooling kW 0.066 0.066 0.076 0.105
Heating kW 0.046 0.046 0.056 0.085
Casing Material Galvanised steel
Dimensions Unit
Height mm 215 215 215 215
Width mm 1110 1110 1110 1310
Depth mm 710 710 710 710
Weight Unit kg 31 31 31 34
Heat
Exchanger
Dimensions
Nr of Rows 2 2 2 3
Fin Pitch
mm 1.75 1.75 1.75 1.75
Face Area
m² 0.180 0.180 0.180 0.226
Nr of Stages 11 11 11 11
Fan
Type
Sirocco fan
Quantity 1 1 1 1
Air Flow Rate Cooling
High m³/min 11.00 11.00 13.00 18.00
Low m³/min 9.00 9.00 10.00 15.00
Fan Motor
Quantity 1 1 1 1
Model 3D12H1AN1V1 3D12H1AN1V1 3D12H1AP1V1 4D12H1AJ1V1
Output
(high)
W15152045
Drive Direct drive
Refrigerant Name R-410A
Cooling
Sound
Pressure
High dBA 38.0 38.0 40.0 42.0
Low dBA 33.0 33.0 34.0 37.0
Piping
connections
Liquid (OD)
Type Flare connection
Diameter
mm 6.4 6.4 6.4 9.5
Gas
Type Flare connection
Diameter
mm 12.7 12.7 12.7 15.9
Drain
Diameter
mm 32 32 32 32
Heat Insulation Foamed Polyethylene
Decoration
Panel
Model BYK45FJW1 BYK45FJW1 BYK45FJW1 BYK71FJW1
Colour
White
Dimensions
Height mm 70 70 70 70
Width mm 1240 1240 1240 1440
Depth mm 800 800 800 800
Weight kg 8.5 8.5 8.5 9.5
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse, Drain pump fuse, Fan motor thermal
Standard Accessories
Installation and operation manual, Metal clamp for drain hose, Clamps, Insulation for hangar bracket,
Positioning Jig for Installation, Paper pattern for installation, Drain hose, Insulation for fitting, Sealing Pads, Screws,
Washer, Air Outlet blocking pad
Notes
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7,5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
Sound pressure levels are measured at 220V
