Specifications SiBE34-802
18 Specifications
Slim Ceiling Mounted Duct Type (with Drain Pump)
1-1 TECHNICAL SPECIFICATIONS FXDQ20M8V3B FXDQ25M8V3B
Nominal
Capacity
Cooling kW 2.20 2.80
Heating kW 2.50 3.20
Power input
(Nominal)
Cooling kW 0.050 0.050
Heating kW 0.050 0.050
Casing
Colour Non painted
Material Galvanised steel
Dimensions
Packing
Height mm 301 301
Width mm 584 584
Depth mm 753 753
Unit
Height mm 230 230
Width mm 502 502
Depth mm 652 652
Weight
Unit kg 17 17
Packed Unit kg 18 18
Required Ceiling Void mm 250 250
Heat
Exchanger
Dimensions
Length mm 430 430
Nr of Rows 2 2
Fin Pitch
mm 1.40 1.40
Nr of Passes 2 2
Face Area
m² 0.108 0.108
Nr of Stages 12 12
Empty Tubeplate
Hole
4
Tube type Hi-XSS (7)
Fin
Fin type Symmetric waffle louvre
Treatment Hydrophilic
Fan
Type Sirocco fan
Quantity 1 1
Air Flow Rate
Cooling
High m³/min 6.70 7.40
Low m³/min 5.20 5.80
Heating
High m³/min 6.70 7.40
Low m³/min 5.20 5.80
Fan Motor
Quantity 1 1
Steps step motor
Output
(high)
W10 10
Drive Direct drive
Refrigerant Name R-410A
Sound Level Cooling
Sound
power
(nominal)
dBA 50.0 50.0
Cooling
Sound
Pressure
High dBA 37.0 37.0
Low dBA 32.0 32.0
Heating
Sound
Pressure
High dBA 37.0 37.0
Low dBA 32.0 32.0
Piping
connections
Liquid (OD)
Type Flare connection
Diameter
mm 6.4 6.4
Gas
Type Flare connection
Diameter
mm 12.7 12.7
Drain
Diameter
mm 27.2 27.2
Air Filter Resin net with mold resistance
Air direction control Up and downwards
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse, Fan motor thermal protector
Standard Accessories Installation and operation manual, Fuse, Caution for servicing sticker, Suction air filter
Notes
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 8m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 8m, level difference : 0m.
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
