Specifications SiBE34-802
24 Specifications
Floor Standing Type
1-1 TECHNICAL SPECIFICATIONS FXLQ20MAVE FXLQ25MAVE FXLQ32MAVE FXLQ40MAVE FXLQ50MAVE FXLQ63MAVE
Nominal
Capacity
Cooling kW 2.20 2.80 3.60 4.50 5.60 7.10
Heating kW 2.50 3.20 4.00 5.00 6.30 8.00
Power input
(Nominal)
Cooling kW 0.049 0.049 0.090 0.090 0.110 0.110
Heating kW 0.049 0.049 0.090 0.090 0.110 0.110
Casing Colour Ivory white (5Y7,5/1)
Dimensions Unit
Height mm 600 600 600 600 600 600
Width mm 1000 1000 1140 1140 1420 1420
Depth mm 222 222 222 222 222 222
Weight Unit kg 25 25 30 30 36 36
Heat
Exchanger
Dimensions
Nr of Rows 3 3 3 3 3 3
Fin Pitch
mm 1.50 1.50 1.50 1.50 1.50 1.50
Face Area
m² 0.159 0.159 0.200 0.200 0.282 0.282
Nr of Stages 14 14 14 14 14 14
Fan
Type Sirocco fan
Quantity 1 1 1 1 1 1
Air Flow Rate Cooling
High m³/min 7.00 7.00 8.00 11.00 14.00 16.00
Low m³/min 6.00 6.00 6.00 8.50 11.00 12.00
Fan Motor
Quantity 1 1 1 1 1 1
Model D14B20 D14B20 2D14B13 2D14B13 2D14B20 2D14B20
Output
(high)
W151525253535
Drive Direct drive
Refrigerant Name R-410A
Cooling
Sound
Pressure
High dBA 35.0 35.0 35.0 38.0 39.0 40.0
Low dBA 32.0 32.0 32.0 33.0 34.0 35.0
Piping
connections
Liquid (OD)
Type Flare connection
Diameter
mm 6.4 6.4 6.4 6.4 6.4 9.5
Gas
Type Flare connection
Diameter
mm 12.7 12.7 12.7 12.7 12.7 15.9
Drain
Diameter
mm O.D. 21
Heat Insulation Glass Fiber/Urethane Foam
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse, Fan motor thermal protector
Standard Accessories Installation and operation manual, Insulation for fitting, Drain hose, Clamps, Screws, Level adjustment screw, Washer
Notes
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7,5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, includinga deduction for cooling (an addition for heating) for indoor fan motor heat.
Sound pressure levels are measured at 220V
