Specifications SiBE34-802
8 Specifications
Heat pump 50Hz <RXYSQ-PA7V1B>
1-1 TECHNICAL SPECIFICATIONS RXYSQ4PA7V1B RXYSQ5PA7V1B RXYSQ6PA7V1B
Capacity
Cooling kW 11.2 14.0 15.5
Heating kW 12.5 16.0 18.0
COP
Cooling 3.99 3.99 3.42
Heating 4.56 4.15 3.94
Capacity range HP 4 5 6
PED category Category I
Max n° of indoor units to be connected 6 8 9
Indoor index
connection
Minimum 50 62.5 70
Maximum 130 162.5 182
Casing
Colour Daikin White
Material Painted galvanised steel
Dimensions
Packing
Height mm 1,524
Width mm 980 980 980
Depth mm 420 420 420
Unit
Height mm 1,345
Width mm 900 900 900
Depth mm 320 320 320
Weight
Unit kg 120 120 120
Packed Unit kg 130 130 130
Packing
Material Carton, wood + EPS
Weight kg 8 8 8
Heat
Exchanger
Dimensions
Length mm 857 857 857
Nr of Rows 2 2 2
Fin Pitch
mm 2 2 2
Nr of Passes101010
Face Area
m² 1,131
Nr of Stages 60 60 60
Tube type Hi-XSS (8)
Fin
Fin type Non-symmetric waffle louvre
Treatment Corrosion resistant
Fan
Type Propeller
Quantity 2 2 2
Air Flow Rate
(nominal at 230V)
Cooling m³/min 106 106 106
Heating m³/min 102 105 105
Discharge direction Horizontal
Motor
Quantity 2 2 2
Model Brushless DC motor
Motor
Speed
(nominal)
Cooling rpm 850/815
Heating rpm 820/785 840/805 840/805
Fan Motor
Drive Direct drive
Output motor
W707070
Compressor
Quantity 1 1 1
Motor
Quantity 1 1 1
Model JT100G-VDL
Type Hermetically sealed scroll compressor
Speed rpm 6,480
Motor Output
kW 2.5 3.0 3.5
Starting Method Direct on line
Crankcase
Heater
W333333
Cooling Standard Min °CDB -5 -5 -5
Operation
Range
Cooling Max °CDB 46 46 46
Heating
Min °CWB -20 -20 -20
Max °CWB 15.5 15.5 15.5
Sound Level
Cooling
Sound Power
dBA666769
Sound Pressure
dBA505153
Heating
Sound Pressure
dBA525355
