12V DC-in Jack

The input power is 12V DC.

Note

Only use the power adapter supplied with IVS-110. Otherwise, the

product may be damaged.

2.2.3 Installation Steps

1. Attach video source to IVS-110

To use IVS-110, user must supply video source to IVS-110. Connect the BNC

terminal of camera to the IVS-110’s video input and make sure to power on

camera rst.

2. Attach Audio source to IVS-110 (option)

If user needs not only video stream but also audio stream, then the audio source

should be attached to IVS-110. Connect the RCA terminal of audio device’s line

output to the IVS-110’s RCA input and make sure to power on your camera or

audio device rst.

3. Plug an Ethernet cable into IVS-110

Connect an Ethernet cable to the LAN socket located on the IVS-110’s panel

and attach it to the network. If there has a PoE switch in your network, you can

connect the IVS-110 LAN cable to this PoE switch to obtain power. The power

adapter is unnecessary when IVS-110 is connected to a PoE switch.

4. Connect RS-485 (option)

When users would like to apply a camera with P/T/Z function, they usually need

to connect their communication port (for camera control) through RS-485. After

RS-485 was correctly connected to D+ and D-, the remote users could control

the camera movement through internet.

5. Connect the external power supply to IVS-110

Plug in power adapter and connect to power source. If there has a PoE switch

in your network, you can connect the IVS-110 LAN cable to this PoE switch to

obtain power. The power adapter is unnecessary when IVS-110 is connected

to a PoE switch. After power on, IVS-110 will start to operate. Once you have

installed the IVS-110 well, the status LED will turn green. It means the system

is booting up successfully. Furthermore, if you have a proper network connec-

tion, and access to the IVS-110, the LED will ash green.

6. Connect the power supply to one external camera (option)

The IVS-110 can provide 12V DC out to supply one external camera. The output

current is 400mA maximum.
