Chapter 3. ICA-310 – 30M Infrared Internet Camera

3.1 Package Content

ICA-310 x 1

Power Adapter x 1

Wall Mount Accessories x 1

CD Disk x 1

Quick Installation Guide x 1

Note

1. if any of the above items are missing, please contact your dealer

immediately.

2. Using a power supply with a different voltage that the one

included with the ICA-310 will cause damage and void the

warranty for ICA-310.

3.2 Physical Installation

1. Connect an Ethernet cable

Connect the LAN cable on the ICA-310 to the network device (hub or switch).

Note

In case you need to connect the device to PC or notebook directly,

you should use cross over cable instead.

2. Connect the power source

Please connect the provided power adapter to ICA-310 power connector and

connect the power plug to power outlet. If there is 802.3af PoE switches in your

network, you can connect the ICA-310 LAN cable to this PoE switch to obtain

power. The power adapter is unnecessary when ICA-310 is connected to a PoE

switch.

Note

PoE and DC adapter only can select one of them
