SUPPLIED ACCESSORIES
The following accessories are supplied with the transceiver.
q Hand microphone ............................................... 1
w Control cable ....................................................... 1
e Ferrite EMI filter ................................................... 1
For European versions ............... 2
r 3.5 (d) mm plug .................................................... 1
t ACC cable ............................................................ 1
y DC power cable* (OPC-1457) ............................ 1
or (OPC-2095) ............................ 1
u Spare fuse (ATC 5 A) ......................................... 1
i USB cable ............................................................ 1
o CD ........................................................................ 1
!0 Spare fuse (ATC 30 A) ....................................... 2
* Depending on the version.
q
w e
r
t
y
y
u
i
o
!0
ABOUT THE SUPPLIED CD
The following instructions and installers are included on
the CD.
• Basic instructions
Instructions for the basic operations, the same as
this manual
• Advanced Instructions
Instructions for the advanced operations and more
details are described than in this manual
• Schematic diagram
Includes the schematic and block diagrams
• HAM radio Terms
A glossary of HAM radio terms
• Adobe
®
Reader
®
Installer
Installer for Adobe
®
Reader
®
A PC with the following Operating System is required.
•Microsoft
®
Windows
®
8,
Microsoft
®
Windows
®
7
, Mi-
crosoft
®
Windows Vista
®
or Microsoft
®
Windows
®
XP
Starting the CD D
Insert the CD into the CD drive. q
•Doubleclick“Autorun.exe”ontheCD.
•Depending on the PC setting, theMenu screen shown
below is automatically displayed.
Click the desired button to open the file. w
•ToclosetheMenuscreen,click[Quit].
To read the guide or instructions, Adobe
®
Reader
®
is
required. If you have not installed it, please install the
Adobe
®
Reader
®
on the CD or downloaded it from Ado-
be Systems Incorporated’s web
site.
QuitsthemenuscreenInstalls the Adobe
®
Reader
®
Opens the
Glossary
Opens the
Basic
Instructions
(this manual)
Opens the
Advanced
Instructions
Opens the
Schematic
diagram
(See p. 2-7 for installation details)
For European versions
