Icom IC-7100 [90/96] Note the default settings shown below in bold are for the usa version the default settings may differ depending on your transceiver version

SET MODE

6-8

Connectors In this item, set the external connector’s options.

USBAudioSQL OFF (OPEN) or ON Selects whether or not to output the audio from

the [USB] connector, according to the squelch

state (open or closed).

ACC/USB Output Select AF or IF Sets the [USB] connector and the [ACC] socket

usage to received audio output or the IF output

for DRM (Digital Radio Mondiale).

ACC/USB AF Level 0%~50 %~100% Sets the audio output level at the [ACC] socket

and the [USB] connector.

ACC/USB IF Level 0%~50 %~100% Sets the IF output level at the [ACC] socket and

the [USB] connector.

ACC MOD Level 0%~50 %~100% Sets the input modulation level at the [ACC]

socket.

DATA MOD Level 0%~50 %~100% Sets the input modulation level at the [DATA]

jack.

USB MOD Level 0%~50 %~100% Sets the input modulation level at the [USB] con-

nector.

DATA OFF MOD MIC, ACC, MIC,ACC or USB Selects the connector(s) for the desired modula-

tion to input when the data mode is not used.

DATA MOD MIC, ACC, MIC,ACC or USB Selects the connector(s) for the desired modula-

tion to input when the data mode is used.

External Keypad

VOICE OFF or ON Selects whether or not to transmit voice memory

contents using the external keypad.

KEYER OFF or ON Selects whether or not to transmit keyer memory

contents using the external keypad.

RTTY OFF or ON Selects whether or not to transmit RTTY memory

contents using the external keypad.

CI-V

CI-V Baud Rate 300, 1200, 4800, 9600, 19200 or Auto Sets the CI-V code transfer speed.

CI-V Address 01h~88h~DFh Sets the transceiver's unique CI-V hexadecimal

address code.

CI-V Transceive OFF or ON Turns the CI-V Transceive function ON or OFF.

USB2/DATA1 Function

USB2 Function OFF, RTTY Decode or DV Data Selects the use of the COM port (USB2).

DATA1 Function OFF, RTTY Decode, DV Data or GPS Select the use of the [DATA1] jack.

GPS Out

OFF or DATA1 g USB2

Selects whether or not to output the data to the

COM port (USB2) when data is input from a GPS

receiver through the [DATA1] jack.

DV Data/GPS Out Baud 4800 or 9600 Sets the DV or GPS data transfer speed

RTTY Decode Baud 300, 1200, 4800, 9600 or 19200 Sets the RTTY decode monitor speed.

VSEND Select OFF, UHF or VHF/UHF Selects the band to use for the [ACC] socket’s pin

7 (VSEND usage).

9600bps Mode OFF or ON Selects whether or not to allow data transmission

at 9600 bps.

Set mode items and Default settings (Continued)

NOTE: The default settings shown below in bold are for the USA version.

The default settings may differ, depending on your transceiver version.
