Section 4 D-STAR INTRODUCTION
IMPORTANT!
•Therepeaterlistdescribedinthismanualmaydifferfromyourtrans-
ceiver’s preloaded contents.
•Although Japanese repeaters are used in the setting examples, the
Japanese repeater node (port) letters are different from those in other
countries.
Be sure to add a repeater node letter as the 8th digit in the call sign
field after a repeater call sign according to the repeater frequency band
shown below.
1200 MHz: A (B in Japan)
430 MHz: B (A in Japan)
144 MHz: C (no D-STAR repeaters in Japan)
“MY” (Your own call sign) programming .............................4-2
D-STAR Introduction .............................................................4-5
About the DR (D-STAR Repeater) mode ..............................4-5
Communication Form in the DR mode ................................4-6
“AI” means “Advanced Instructions.”
“sec. MM” means section number.
So when “(AI sec. MM)” is described on this manual, see the PDF type
Advanced Instruction’s section number for your reference.
