SET MODE
6-7
Tone Control In this item, set the RX/TX tone control options.
RX
SSB
RX HPF/LPF ---- – ----,100~2000–500~2400 Sets the high-pass filter or low-pass filter of the
receive audio.
RX Bass –5~0~+5 Sets the bass level of the receive audio.
RX Treble –5~0~+5 Sets the treble level of the receive audio.
AM
RX HPF/LPF ---- – ----,100~2000–500~2400 Sets the high-pass filter or low-pass filter of the
receive audio.
RX Bass –5~0~+5 Sets the bass level of the receive audio.
RX Treble –5~0~+5 Sets the treble level of the receive audio.
FM
RX HPF/LPF ---- – ----,100~2000–500~2400 Sets the high-pass filter or low-pass filter of the
receive audio.
RX Bass –5~0~+5 Sets the bass level of the receive audio.
RX Treble –5~0~+5 Sets the treble level of the receive audio.
DV
RX HPF/LPF ---- – ----,100~2000–500~2400 Sets the high-pass filter or low-pass filter of the
receive audio.
RX Bass –5~0~+5 Sets the bass level of the receive audio.
RX Treble –5~0~+5 Sets the treble level of the receive audio.
WFM
RX Bass –5~0~+5 Sets the bass level of the receive audio.
RX Treble –5~0~+5 Sets the treble level of the receive audio.
CW
RX HPF/LPF ---- – ----,100~2000–500~2400 Sets the high-pass filter or low-pass filter of the
receive audio.
RTTY
RX HPF/LPF ---- – ----,100~2000–500~2400 Sets the high-pass filter or low-pass filter of the
receive audio.
TX
SSB
TX Bass –5~0~+5 Sets the bass level of the transmit audio.
TX Treble –5~0~+5 Sets the treble level of the transmit audio.
TBW (WIDE) 100, 200, 300, 500 – 2500, 2700,
2800, 2900
Sets the lower and higher cut-off frequencies to
change the transmission passband width for the
wide setting.
TBW (MID) 100, 200, 300, 500 – 2500, 2700,
2800, 2900
Sets the lower and higher cut-off frequencies to
change the transmission passband width for the
mid setting.
TBW (NAR) 100, 200, 300, 500 – 2500, 2700,
2800, 2900
Sets the lower and higher cut-off frequencies to
change the transmission passband width for the
narrow setting.
AM
TX Bass –5~0~+5 Sets the bass level of the transmit audio.
TX Treble –5~0~+5 Sets the treble level of the transmit audio.
FM
TX Bass –5~0~+5 Sets the bass level of the transmit audio.
TX Treble –5~0~+5 Sets the treble level of the transmit audio.
DV
TX Bass –5~0~+5 Sets the bass level of the transmit audio.
TX Treble –5~0~+5 Sets the treble level of the transmit audio.
Set mode items and Default settings (Continued)
NOTE: The default settings shown below in bold are for the USA version.
The default settings may differ, depending on your transceiver version.
