D-STAR OPERATION <BASIC>

5-4

D-STAR Operating procedures (Continued)

INTERNET

JA3YUA calling to

JP1YIU port A through

JP3YHH port B.

JM1ZLK, this is JA3YUA.

ThanksfortheniceQSOandI

hope to talk to you again soon.

This is JA3YUA now clear of

the JP3YHH repeater.

JA3YUA, this is JM1ZLK.

Hello,howareyou?

< Communication example for a Gateway call>

•
